| Installation Type |
Rack, Work bench, Against the wall |
| Cabinet Installation Standard |
Cabinet with a depth of 300 mm or above |
| Dimensions without Packaging (H x W x D) |
– Typical: 43.6 mm x 250 mm x 210 mm |
|
– Maximum: 43.6 mm x 250 mm x 220 mm |
| Dimensions with Packaging (H x W x D) |
110 mm x 470 mm x 335 mm |
| Chassis Height |
1U |
| Weight with Packaging |
2.3 kg (5.07 lb) |
| Weight without Packaging |
1.57 kg (3.46 lb) |
| CPU |
1 CPU, 4 cores/CPU, up to 1.2 GHz |
| Memory |
2 GB DDR4 ECC memory |
| NOR Flash |
64 MB |
| NAND Flash |
2 GB |
| Hard Disk |
Optional (64-GB micro SD card from Huawei) |
| Console Port |
RJ45 |
| Eth Management Port |
RJ45 |
| Typical Power Consumption |
16.4 W |
| Maximum Power Consumption |
22.3 W |
| Maximum Heat Dissipation |
76.08 BTU/hour |
| MTBF |
57.29 years |
| MTTR |
2 hours |
| Availability |
0.999996 |
| Power Supply Mode |
Power adapter (external) |
| Number of Power Modules |
1 |
| Rated Input Voltage |
100 V to 240 V, 50 Hz/60 Hz |
| Input Voltage Range |
90 V to 264 V, 47 Hz to 63 Hz |
| Maximum Input Current |
1 A/power module |
| Rated Output Power |
36 W/12V |
| Maximum Output Power |
36 W/power module |
| Types of Fans |
None |
| Number of Fan Modules |
0 |
| Heat Dissipation Mode |
Natural cooling (no fan) |
| Long-term Operating Temperature |
0°C to 45°C (32°F to 113°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Long-term Operating Relative Humidity |
5% RH to 95% RH, non-condensing |
| Storage Relative Humidity |
5% RH to 95% RH, non-condensing |
| Long-term Operating Altitude |
0 m to 5000 m (0 ft to 16404.2 ft) |
| Storage Altitude |
0 m to 5000 m (0 ft to 16404.2 ft) |
