Moxa EDS-G308 Unmanaged Switch Price in Doha Qatar
- Fiber-optic options for extending distance and improving electrical noise immunity
- Redundant dual 12/24/48 VDC power inputs
- Supports 9.6 KB jumbo frames
- Relay output warning for power failure and port break alarm
- Broadcast storm protection
- -40 to 75°C operating temperature range (-T models)
- Description
- Reviews (0)
Description
Description
Input/Output Interface
-
Alarm Contact Channels
1 relay output with current carrying capacity of 1 A @ 24 VDC
Ethernet Interface
-
10/100/1000BaseT(X) Ports (RJ45 connector)
EDS-G308/G308-T: 8
EDS-G308-2SFP/G308-2SFP-T: 6All models support:
Auto negotiation speed
Full/Half duplex mode
Auto MDI/MDI-X connection -
Combo Ports (10/100/1000BaseT(X) or 100/1000BaseSFP+)
EDS-G308-2SFP: 2
EDS-G308-2SFP-T: 2 -
Standards
IEEE 802.3 for 10BaseT
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3x for flow control
IEEE 802.3z for 1000BaseX
IEEE 802.3az for Energy-Efficient Ethernet
DIP Switch Configuration
-
Ethernet Interface
Broadcast storm protection, Jumbo Frame, IEEE 802.3az energy saving, 100/1000 SFP speed switching, Port break alarm
Switch Properties
-
Jumbo Frame Size
9.6 KB
-
MAC Table Size
8 K
-
Packet Buffer Size
4 Mbits
-
Processing Type
Store and Forward
Power Parameters
-
Connection
1 removable 6-contact terminal block(s)
-
Input Voltage
12/24/48 VDC, Redundant dual inputs
-
Operating Voltage
9.6 to 60 VDC
-
Reverse Polarity Protection
Supported
-
Input Current
EDS-G308: 0.29 A @ 24 VDC
EDS-G308-2SFP: 0.31 A @ 24 VDC
Physical Characteristics
-
Housing
Metal
-
IP Rating
IP30
-
Dimensions
52.85 x 135 x 105 mm (2.08 x 5.31 x 4.13 in)
-
Weight
880 g (1.94 lb)
-
Installation
DIN-rail mounting, Wall mounting (with optional kit)
Environmental Limits
-
Operating Temperature
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F) -
Storage Temperature (package included)
-40 to 85°C (-40 to 185°F)
-
Ambient Relative Humidity
5 to 95% (non-condensing)
Standards and Certifications
-
EMC
EN 55032/35
-
EMI
CISPR 32, FCC Part 15B Class A
-
EMS
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 800 MHz: 10 V/m
IEC 61000-4-3 RS: 800 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF: 100 A/m -
Hazardous Locations
ATEX, Class I Division 2
-
Maritime
DNV
-
Railway
EN 50121-4
-
Safety
UL 508, EN 62368-1
-
Shock
IEC 60068-2-27
-
Freefall
IEC 60068-2-32
-
Vibration
IEC 60068-2-6
MTBF
-
Time
2,260,195 hrs
-
Standards
Telcordia (Bellcore), GB
Warranty
-
Warranty Period
5 years
