| Fingerprint Capacity |
4,000 |
| Face Capacity |
2,000 (1:N) / 4,000 (1:1) |
| Card Capacity |
10,000 |
| Transactions Capacity |
100,000 |
| User Photos |
4,000 |
| Event Photos |
2,000 |
| Communication |
TCP/IP, RS485 (For Slave Reader), USB Host, Wiegand Input / Output, Security Relay Box |
| Hardware |
1.2GHz Dual Core CPU, Memory 128MB RAM / 256MB Flash, SilkID Fingerprint Sensor, 2,8 Inches TFT-LCD Touch Screen, 125KHz EM Reader / Mifare (Optional), Hi-Fi Voice & Indicator, Tamper Switch Alarm, Dual IR Camera |
| Standard Functions |
Access Levels / Groups / Holidays , DST / Bell Schedule, Duress Mode, Anti-Passback, Record Query, Custom Wallpaper & Screen Saver |
| Special Functions |
Multiple Biometric Verification Modes, Alive Finger Detection, Event Snapshot, User Photo |
| Access Control Interface |
Lock Relay Output, Alarm Output / Auxiliary Input, Exit Button / Door Sensor, Doorbell Output |
| Compatibility |
Wiegand Slave Reader, RS485 FP Slave Reader , ZKBioSecurity Software |
| Working Temperature |
-10 °C ~ 50 °C |
| Dimensions |
190.8 × 85 × 103 mm |
| Algorithm |
ZKFace v7.0 & ZKFinger v10.0 Algorithms |
| Power |
Operating Voltage 12V DC, Current Draw < 500 mA |
