| Capacity |
Fingerprint: 20,000 |
| Card: 10,000 |
| Transaction: 100,000 |
| Communication |
TCP/IP |
| RS485 (For Slave Reader), Wiegand Input / Output, Security Relay Box |
| Access Control Interface |
Lock Relay Output, Alarm Output / Auxiliary Input |
| Exit Button / Door Sensor, Doorbell Output |
| Hardware |
1.2GHz High Speed CPU |
| Memory 128MB RAM / 256MB Flash |
| BioID Fingerprint Sensor, 2.4 Inches TFT-LCD Screen |
| 125KHz EM Reader / Mifare (Optional), Hi-Fi Voice & Indicator |
| Anti-dismantle Alarm, Touch Keypad |
| Standard Functions |
Access Levels / Groups / Holidays |
| DST / Bell Schedule |
| Duress Mode, Anti-Passback, Record Query |
| Custom Wallpaper & Screen Saver |
| Special Functions |
Multiple Verification Modes, ZK Encrypted Card (Optional) |
| Fingerprint Card (Optional) |
| Compatibility |
Wiegand Slave Reader, RS485 FP Slave Reader |
| ZKBioSecurity Software |
| Additional Info |
Working Temperature: -10 °C ~ 50 °C |
| Dimensions: 202.30×96.80×35.00mm. |
| Fingerprint Algorithm ZKFinger v10.0 |
| Fingerprint: FAR≤0.0001% FRR≤0.01% |
| Package Includes 12V 3A Power Supply |
| Power |
Operating Voltage 12V DC, Current Draw < 500mA |
